Model
SC02-I365A
SC02-I375A
SC02-I386A
-
Screen Size
65 inch
75 inch
85 inch
-
Backlight
D-LED
-
Backlight Life
50,000 hours (min.) (typ.)
-
Resolution
3840 × 2160 (pixels)
-
Brightness
450cd/m²(typ.)
-
Contrast Ratio
3000:1 (typ.)
-
Response Time
8ms (typ.)
-
Refresh Frequency
60Hz
-
Aspect Ratio
16:09
-
View Angle
178°(H) / 178°(V)
-
Bonding Technology
The gap between tempered glass and screen is close to 0
-
Display Colors
1.07B(8bit+FRC)
-
Touch Technology
Advanced infrared touch technology
-
Touch Points
Up to 50
-
Touch Response Time
Single touch: ≤ 3ms
Multiple touch: ≤3 ms
-
Accuracy
Center 90% touch area: 1mm
-
Anti-Glare
High transparent+Smooth+Anti-glare
-
Glass Hardness
9H (Pencil Hardness) ; 7(Mohs Hardness) Tempered Glass
-
Writing Height
≤ 1mm
-
CPU
Quad core A73+Quad core A53
-
GPU
MaliG52 MP8
-
Memory (RAM)
8GB
-
Storage (ROM)
128GB
-
Operating System
Android 14 / Windows 11 (Optional)
-
Front Port
USB 3.0*2
Type-C(65W)*1
-
Bottom Port
AUDIO IN*1
VGA*1
LAN IN/OUT*2
RS232*1
MIC IN*1
HDMI OUT*1
AUDIO OUT*1
SPDIF*2
-
Side Port
Touch-USB*2
DP*1
HDMI IN(ARC) 1 2.0*1
HDMI IN(CEC) 2 2.0*1
Type-C*1
USB 2.0*1
USB 3.0*2
OPS slot (for slot-in PC)*1
-
Wi-Fi
Wi-Fi 6: IEEE 802.11 ax/ac/b/g/n (5GHz / 2.4GHz)
-
Bluetooth
BT 5.0: 2.1+EDR/4.2/5.0
-
NFC
ISO / IEC 14443 A ; ISO / IEC 14443 B
-
Camera
Pixel : 48 Mega pixels
FOV : FOV Diagonal 114.9°
Face tracking : Support
Sound localization : Support
-
Microphone
Array quantity : 8 microphones array
Pickup Range : Support
3D noisereduction : Support
AEC & AGC : Support
-
Speaker
2*20W+1*20W(Subwoofer optional)
-
Operating Power
100 V ~ 240 V/AC, 50/60 Hz
-
Standby power consumption
<0.5W
-
Power consumption (100% brightness)
178W (typ.)
215W (typ.)
278W (typ.)
-
Dimensions (W × H × D)
1483.9*86.7*911.6mm
1705*86.9*1036mm
1950.4 *86.9 *1174mm
-
Package Dimensions (L × W × H)
1640*185*1010mm
1860*185*1125mm
2095*185*1265mm
-
Net Weight (kg)
40.5kg
53.95kg
66.85kg
-
Weight with Packaging (kg)
50.2kg
64.5kg
79.05kg
-
Case Material
Aluminium Alloy and Sheet Metal
-
Color
Blue grey
-
Lifespan
50000 Hours (Expected)
-
Operating Temperature
0°C to 40°C
-
Storage Temperature
10°C to 60°C
-
Operating Humidity
20% to 80% RH (Non-condensing)
-
Storage Humidity
10% to 60% RH (Non-condensing)
-
Cables
Power Cable*1, USB Cable*1, HDMI Cable*1
-
Remote Controller
1
-
Stylus Pen
2
-
Wall mount
1
-
Eraser
1
-
Movable bracket
YES
-
OPS
YES
-
Wireless Dongle
YES
